Brake Tester – Vehicle brake tester
Brake tester
- Can test Brake Force, Brake Efficiency, Brake Imbalance, Friction Efficiency, Axle Load and Ovality.
- It can be used in garages, MOT test and vehicle inspection stations.
- Vehicle brake tester compose as a vehicle safety test lane with Suspension Tester, Sideslip Tester and Speedometer.
- The corundum roller has more than 200,000 life span.
- High testing speed, can truly reflect the Vehicle braking performance.
- Combined with weighing function.
- With Slip Rate testing to stop the motor, protect the tires from wear.
- The brake performance result data can be saved and printed on Jevol Computer Control System, or show directly on Jevol Digital Display.
- Pedal Force Meter is optional, according to some country’s requirement.
- Customizable test speed
- Vehicle brake tester is compact bench, fully galvanized bench can be customized
- With a protective cover to easy the driving of the vehicle
- Click to see: Truck Brake Tester, Mobile Brake Tester, Motorcycle Brake Tester
For more information please
Delivery, installation and calibration not included
Specifications
| Item | RRT-2500 | RRT-2500W |
|---|---|---|
| Max axle load | 3 T | 3 T |
| Test speed | 2.5 km/h | 3.7 km/h |
| Brake force range | 0-9000 N | 0-9000 N |
| Motor | 3 kW *2 | 3 kW *2 |
| Power supply | 380V 50Hz | 380V 50Hz |
| Adhesion coefficient | 0.8 | 0.8 |
| Roller diameter | 245 mm | 200 mm |
| Roller length | 750 mm | 700 mm |
| Dimensions (L×W×H) | 2500×750×360 mm | 2400×680×305 mm |
| Application | 2 WD | 4 WD & 2 WD |
